설계CAD / CAM / CAE
| NO | TYPE | S/W | MAKER | QTY |
|---|---|---|---|---|
| 1 | CAD | NX | SIMENS | 5 |
| 2 | CAD | AUTO CAD | AUTODESK | 8 |
| 3 | CAD | GSTAR CAD | GSTAR SOFT | 1 |
| 4 | CAD SUPPORT | T-MOLD | SPACE SOLUTION | 3 |
| 5 | CAD SUPPORT | NX PLUS | JIN SOFT | 1 |
| 6 | CAE | MOLD FLOW | AUTODESK | 1 |
| 7 | CAM | POWER MILL | AUTODESK | 6 |
설비/인증현황
금형사업부 설비현황
가공MCT
| NO | TYPE | MODEL | MAKER | SPEC | MFD |
|---|---|---|---|---|---|
| 1 | MCT | SIRIUS-1350 | HWACHEON | 2550 X 1350 X 750, RPM 8000 | 2017 |
| 2 | MCT | SIRIUS-1250 | HWACHEON | 2500 X 1250 X 750, RPM 8000 | 2014 |
| 3 | MCT | SIRIUS-1250 | HWACHEON | 2500 X 1250 X 750, RPM 8000 | 2012 |
| 4 | MCT | SIRIUS-1250 | HWACHEON | 2500 X 1250 X 750, RPM 8000 | 2005 |
| 5 | MCT | SIRIUS-700 | HWACHEON | 1100 X 700 X 650, RPM 12000 | 2011 |
| 6 | MCT | SIRIUS-700 | HWACHEON | 1100 X 700 X 650, RPM 12000 | 2009 |
| 7 | MCT | SIRIUS-UL+ | HWACHEON | 1050 X 600 X 550, RPM 20000 | 2019 |
| 8 | MCT(Electrode) | SMART UaX | HWACHEON | 1300 X 750 X 420, RPM 20000 | 2020 |
| 9 | MCT(Electrode) | VESTA-1000 | HWACHEON | 1000 X 550 X 500, RPM 10000 | 2012 |
가공EDM / WIRE CUTTING
| NO | TYPE | MODEL | MAKER | SPEC | MFD |
|---|---|---|---|---|---|
| 1 | EDM | HG-150 | HANSPARK | 1000 X 600 X 500 | 2019 |
| 2 | EDM | HE-130B | HANSPARK | 800 X 600 X 400 | 2015 |
| 3 | EDM | HE-130B | HANSPARK | 800 X 600 X 400 | 2015 |
| 4 | WIRE CUTTING | EZ40S | SPM | 800 X 500 X 350 | 2015 |
| 5 | WIRE CUTTING | EZ40S(500T) | SPM | 800 X 500 X 500 | 2015 |
기타설비
| NO | TYPE | MODEL | MAKER | SPEC | MFD |
|---|---|---|---|---|---|
| 1 | DIE SPOTTING PRESS | DSP-1205-D102 | CMTI | 2500 X 1500 X 2000, 300TON | 2012 |
| 2 | MILLING MACHINE | HMT-1100 | HWACHEON | 750 X 300 X 450, RPM 3600 | 2003 |
| 3 | MILLING MACHINE | HMT-1100N | HWACHEON | 750 X 300 X 450, RPM 3600 | 2001 |
| 4 | GRINDING MACHINE | DGS 520MB | DAESAN | 500 X 180 X 400, RPM 3450 | 2023 |
| 5 | GRINDING MACHINE | DGS 520MB | DAESAN | 500 X 180 X 400, RPM 3450 | 2005 |
| 6 | LATHE(선반) | MECA TURN | NAMSUN | 300 X 1000, RPM 1800 | 1996 |
| 7 | RADIAL MACHINE | RE3-1600 | OOYA | 1600mm | 1980 |
사출
| NO | TYPE | MODEL | MAKER | SPEC | MFD |
|---|---|---|---|---|---|
| 1 | INJECTION MOLDING MACHINE | PRO DIMA-1300 | DONGSHIN | 1300T | 2009 |
| 2 | INJECTION MOLDING MACHINE | SELEX EM850 | WOOJIN | 850T | 2002 |
| 3 | INJECTION MOLDING MACHINE | SELEX EM450 | WOOJIN | 450T | 2000 |
| 4 | INJECTION MOLDING MACHINE | PRO-WD SERIES | DONGSHIN | 150T | 2003 |
품질
| NO | TYPE | MODEL | MAKER | SPEC | MFD |
|---|---|---|---|---|---|
| 1 | 3D CMM | SIGMA | DUKIN | 700 X 1000 X 600 | 2009 |
